BRAVO TECHNOLOGY CENTER
Lexmark Optra T644N, T644TN, T644DTN Compiled by   Sam C. Chan


Lexmark Workhorse History   JAN 2015
1987? 4039-10R   (IBM)
1991 4049-12R   @divestment
1995 Optra R   first major line post-divestment
2000 Optra T630
2004 Optra T640
2009 Optra T650
2014 MS810

First Publish: February 2, 2005
Last updated:
June 29. 2007
ARCHIVED:   NOV 2009

Status:  Legacy Bravo PSL0



Notable Features:

  • 50PPM speed
  • Commercial Workhorse Grade
    duty, dependability & serviceability
  • 1.02¢/page: Extra High Yield Prebate cartridge
  • Secure Print Job pick-up
  • Direct print: pictures & pdf via USB flash drives
  • PCL5e, PCL6, Postscript 3 & PPDS
  • Resident OCR-A & OCR-B for MICR
  • Simultaneous TCP/IP, IPX/SPX, Appletalk. Lexlink
  • Well-proven IT management features
  • Free Advanced Exchange (next business day)
  • Official Bravo BSSO/PSL0 designation

Lexmark Optra T644 Specifications
Print Technology Monochrome Laser
UNSPSC Code 43.21.21.05
Bravo-Recommended Toner Cartridge 64415XA 32K Extra Hi Yield Prebate
Note: Printer functions only with cartridges designed for use in the United States and Canada. A total of 8 different cartridges available for this printer.
Print Speed (Letter, Black): Up to 50 ppm
Print Speed (A4, Black): Up to 48 ppm
Time to First Page (Black) as fast as 8.5 seconds
Print Resolution, Black 1200 Image Quality
1200 x 1200 dpi
2400 Image Quality

600 x 600 dpi
Processor 514 MHz
Memory, Standard 128 MB
Memory, Maximum 640 MB
Expandable Memory Options Yes
Apple Macintosh Operating Systems Supported Apple Mac OS X
Apple Mac OS 9.x
Citrix MetaFrame Presentation Server or Citrix MetaFrame Presentation Server 3.0.
Microsoft Windows Server 2003 running Terminal Server with Citrix MetaFrame XP Microsoft Windows Server 2003 running Terminal Server with Citrix Presentation Server 4.0
Linux Operating Systems Supported Red Hat Linux 7.3, 8.0, 9.0
Red Flag Linux Desktop 4.0, 5.0
Linpus Linux Desktop 9.2, 9.3
Red Hat Enterprise Linux WS 3.0, 4.0, 5.0
SUSE Linux Enterprise Server 8.0, 9.0, 10.0
SUSE Linux Professional 9.1, 9.2, 9.3
Debian GNU/Linux 3.1
Linspire Linux 5.0
Microsoft Windows Operating Systems Supported Microsoft Windows 2000
Microsoft Windows NT (4.00/4.00 Server)
Microsoft Windows Me
Microsoft Windows XP
Microsoft Windows Server 2003
Microsoft Windows 98 2nd Edition
Microsoft Windows XP x64
Microsoft Windows Server 2003 running Terminal Server
Microsoft Windows 2000 Server running Terminal Services
Microsoft Windows Server 2003 x64 Edition
Microsoft Windows Server 2003 x64 Edition running Terminal Services
Microsoft Windows Vista
Microsoft Windows Vista x64
Novell Operating Systems Supported Novell® Open Enterprise Server for Netware with NDS, iPrint or Novell Distributed Print Services (NDPS)
Novell NetWare® 3.2, 4.2 (bindery)
Novell NetWare 4.2, 5.x and 6.x (NDS)
Novell NetWare 5.x, 6.x with iPrint or Novell Distributed Print Services (NDPS)
Other Operating Systems Supported IBM iSeries or IBM AS/400® Systems with TCP/IP with OS/400® V3R1 or later using OS/400 Host Print Transform
Virtually any platform supporting TCP/IP
UNIX Operating Systems Supported Sun Solaris SPARC 7, 8, 9, 10
HP-UX 11.00, 11.1
IBM AIX 5.1, 5.2, 5.3
Paper Handling Standard 500-Sheet Output Bin
500-Sheet Input Tray
100-Sheet Multipurpose Feeder
Paper Handling Optional 1,850-Sheet High-capacity Output Stacker
250-Sheet Universally Adjustable Tray with Drawer
400-Sheet Universally Adjustable Tray with Drawer
5-Bin Mailbox
650-Sheet Output Expander
Envelope Feeder  (20G0891)
StapleSmart Finisher
250-Sheet Drawer
500-Sheet Drawer
500-Sheet Duplex Unit

2,000-Sheet High-capacity Feeder
Paper Input Capacity (Standard/Maximum) 600 / 4100 pages   pages 20 lb or 75 gsm bond
Paper Output Capacity (Standard/Maximum) 500 / 3000  pages 20 lb or 75 gsm bond
Envelope Capacity 85
Finishing Option? Yes
Number of Paper Inputs
(Standard/Maximum)
2 / 6
Media Types Supported Card Stock
Dual Web Labels
Envelopes
Integrated Labels
Paper Labels
Plain Paper
Polyester Labels
Transparencies
Vinyl Labels
Refer to the Card Stock & Label Guide
Media Sizes Supported 10 Envelope
7 3/4 Envelope
9 Envelope
A4
A5
DL Envelope
Executive
Folio
JIS-B5
Legal
Letter
Statement
Universal
Supplies Yield 6,000*-page Print Cartridge
21,000*-page High Yield Print Cartridge
32,000*-page Extra High Yield Print Cartridge
Ships with 21,000*-page High Yield Return Program Print Cartridge
*Average standard page yield value declared in accordance with ISO/IEC 19752.
Standard Ports Centronics IEEE 1284 Bidirectional Parallel
Two Internal Card Slots
USB Compatible with USB 2.0 Specification
USB Direct interface on Operator Panel
Optional Local Ports Internal RS-232C serial
Internal 1284-B Bidirectional Parallel
Optional Network Ports Coax/Twinax Adapter for SCS
Lexmark N4000e Fast Ethernet (Print Only)
Lexmark N4050e 802.11g Wireless Print Server (Print Only)
Internal MarkNet™ N8020 GigaBit Ethernet
Internal MarkNet™ N8050 802.11g Wireless
External MarkNet™ N7020e Gigabit Ethernet
External MarkNet™ N7000e Fast Ethernet (USB)
External MarkNet™ N7002e Fast Ethernet (parallel)
Internal MarkNet™ N8030 Fiber Fast Ethernet
Internal MarkNet™ N8000 Fast Ethernet
Fonts and Symbol Sets 3 of 9 scalable PCL 5e fonts in Narrow, Regular and Wide
158 scalable PostScript fonts
2 PCL bitmap fonts
39 scalable PPDS fonts
5 PPDS bitmap fonts
84 scalable PCL fonts
OCR-A, OCR-B scalable PCL 5e fonts
For more information, refer to the Technical Reference.
Printable Area 0.167 inches of the top, bottom, right and left edges (within)
Printable Area (metric) 4.2 mm of the top, bottom, right and left edges (within)
Printer Languages (Standard) PCL 5e Emulation
PCL 6 Emulation
Personal Printer Data Stream (PPDS
PostScript 3 Emulation
PDF 1.5
Size (mm - H x W x D) 406 x 436 x 523  mm
Size (" - H x W x D) 16 x 17.2 x 20.6  "
Weight (kg) 23.1 kg
Weight (lbs) 51 lbs.
Packaged Size (mm - H x W x D) 533 x 518 x 591 mm
Packaged Size (" - H x W x D) 21 x 20.38 x 23.25 "
Packaged Weight (kg) 25.78 kg
Packaged Weight (lbs) 56.84 lbs.
Noise Level, Idle 30 dBA
Print Noise Level, Operating 55 dBA
Product Warranty One Year Advanced Exchange
Product Certifications CSA, ICES Class B, BSMI Class B, VCCI Class B, FCC Class B, UL 60950 3rd Edition, IEC 320-1, CE Class B, CB IEC 60950, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, C-tick Class B CCC Class B
Duty Cycle: Up to 250,000 one-time maximum Impressions per month
Specified Operating Environment Temperature: 16 to 32°C (60 to 90°F)
Humidity: 8 to 80% Relative Humidity
Altitude: 0 - 3048 Meters (10,000 Feet)
