Lexmark Workhorse
Mono Laser History
1987 4039-10R
(IBM)
1991 4049-12R @divestment
1995 Optra R first major
line post-divestment
1998 Optra S
2000 Optra T630
2004 Optra T640
2009 Optra T650
2014 MS810
2018 MS823
|
|
First Published: December 14,
2009
Last updated: April 9. 2019
Status: current Bravo PSL0
|
|
Notable Features:
- 55 ppm, Commercial Workhorse
Grade
duty, dependability & serviceability
- 1.1¢/page: Extra
High Yield rtn pgm print cartridge
- Confidential Print & Hold
- Watermark & Overlay. HDD optional.
- Direct print: html, pictures &
pdf via USB flash drives
- PCL5e, PCL6, Postscript
3 & PPDS
- Resident OCR-A & OCR-B for MICR
- Simultaneous TCP/IP,
IPX/SPX, Appletalk. Lexlink
- Well-proven IT management
features
- Free Advanced Exchange
(next business day)
- Official Bravo BSSO/PSL0
designation
|
Lexmark Optra T654 Specifications
|
TLI/Part# 30G0310
Machine Type# 4062-xxx Config/CID# xxxYxx S/N# xxxxxxx
|
| Display |
4-line 160 x 64 pixel All Points Addressable (APA)
backlit gray-scale display
|
| Media Sizes |
7 3/4 Envelope, A6 Card, 9 Envelope, JIS-B5, A4,
Legal, A5, Letter, Statement, Executive, Universal, DL Envelope, Folio,
10 Envelope
|
| Standard Ports |
Front USB 2.0 Specification Hi-Speed Certified port
(Type A), Rear USB 2.0 Specification Hi-Speed Certified Port (Type A),
Ethernet 10/100BaseTX (RJ-45), also works with 1000Base-T, USB 2.0
Specification Hi-Speed Certified (Type B), One Internal Card Slot
|
Dimemsion
|
17.2 x 16.7 x 20.1 in. (HWD)
|
| Weight |
51.6 lb. pkg 22x25x22" 57 lb
|
Printing
| Speed |
55 ppm
|
| 1st Page |
Black: 7.5 seconds
|
| Resolution |
Black: 1200 x 1200 dpi, 2400 Image Quality, 600 x 600
dpi, 1200 Image Quality
|
| Printable |
0.167 inches of the top, bottom, right and left edges
(within)
|
Paper Handling
| Media |
Vinyl Labels, Integrated Labels, Paper Labels, Card
Stock, Plain Paper, Polyester Labels, Dual Web Labels, Transparencies,
Envelopes
|
| Finishing
|
Optional
|
| #Inputs |
Standard 2 MAX 6
|
| Input |
650 pages 20 lb/75 gsm bond MAX 4300
pages
|
| Output |
550 pages 20 lb/75 gsm bond MAX 2950 pages
|
| Paper Wt |
16 - 47 lb. (Standard Tray (lb.))
|
| Paper Handling |
100-Sheet Multipurpose Feeder, 550-Sheet Output Bin,
550-Sheet Input Tray
optional: 1,850-Sheet High-Capacity Output Stacker, 5-Bin
Mailbox, 550-Sheet Drawer, 250-Sheet Drawer, 200-Sheet Universally
Adjustable Tray with Drawer, Envelope Feeder, StapleSmart II Finisher,
Optional furniture required., 550-Sheet Output Expander, 400-Sheet
Universally Adjustable Tray with Drawer, 2,000-Sheet High Capacity
Feeder (Caster Base required)
|
| Duty Cycle |
5,000 - 50,000 pages recommended, max 300,000
pages per month
|
Cartridges
| Yield |
#T654X11A
36,000-page Extra High Yield / 7,000-pg /
25,000-pg High Yield
|
| Initial |
10,000-page starter Return Program Print Cartridge
|
Hardware
| Processor |
600 MHz
|
| Memory |
Standard: 256 MB / Maximum: 1280 MB
|
| Hard Disk |
Option available
|
| Printer Languages |
Standard: PDF 1.6 emulation, PCL 5e Emulation, PCL 6 Emulation,
Microsoft XPS (XML Paper Specification), Personal Printer Data Stream
(PPDS), xHTML, PostScript 3 Emulation, Direct Image
|
| Fonts and Symbol Sets |
2 PCL bitmap fonts, 158 scalable PostScript fonts,
OCR-A, OCR-B scalable PCL 5e fonts, For more information, refer to the
Technical Reference., 84 scalable PCL fonts, 3 of 9 scalable PCL 5e
fonts in Narrow, Regular and Wide, 5 PPDS bitmap fonts, 39 scalable
PPDS fonts
|
Connectivity
|
Direct USB |
Yes
|
|
Ethernet |
Yes
|
| Protocol s |
TCP/IP IPv6, IPX/SPX, TCP/IP IPv4, LexLink (DLC),
AppleTalk™, TCP, UDP
|
| Network Print Methods |
LPR/LPD, Socket (Raw TCP/IP), Direct IP (Port 9100),
HTTP, IPP 1.1 (Internet Printing Protocol), NDPS/NEPS (Novell
Distributed Print Services, Novell Netware Enterprise Print Services),
NDS Queue-based Printing, FTP, TFTP, Enhanced IP (Port 9400), ThinPrint
.print integration
|
| Network Management Protocols |
DHCP, APIPA (AutoIP), BOOTP, RARP, mDNS, IGMP,
Bonjour, WINS, DDNS, SNMPv3, SNMPv2c, Telnet, NTP, ICMP, HTTP, DNS,
ARP, HTTPs (TLS 1.2 compliant
per BTC, PCI, GDPR), Finger
|
| Security |
IPSec, SNMPv3, 802.1x Authentication: MD5, MSCHAPv2,
LEAP, PEAP, TLS, TTLS
|
|
SMBv3
fully supported -per BTC ban of
SMBv1 2016
Non-Java HTML5 panel -per BTC
Java ban 2014
|
| Optional Local Ports |
Internal 1284-B Bidirectional Parallel, Internal
RS-232C serial
|
| Optional Ports |
External MarkNet N7020e Gigabit Ethernet, Internal
MarkNet™ N8120 Gigabit Ethernet, Internal MarkNet™ N8150 802.11b/g/n
Wireless, Lexmark N4050e 802.11g Wireless Print Server (Print Only),
Internal MarkNet™ N8130 Fiber Fast Ethernet
|
Electrical & Operation
| Noise Level |
30 dBA (Idle) 55 dBA (Print)
|
| Average Power |
740 watts (Printing)
|
| Standby |
14 watts/85 watts
|
| Harmonized Tariff Code |
8443.32.1010
|
| Country of Origin |
China (PRC)
|
